In the field of electronic heat dissipation and temperature control, semiconductor cooling plates are widely used due to their advantages such as high efficiency, noiselessness, and vibration-free operation. However, to fully leverage the performance of semiconductor cooling plates, it is crucial to accurately calculate their actual power requirements. Improper power matching can lead to low energy efficiency or even device damage. In this article, HuaJing Temperature Control will explore the calculation formula and derivation process for the cooling power of semiconductor cooling plates, as well as introduce the use of online calculation tools to help you clearly understand your cooling power needs.

Cooling Principle of Semiconductor Cooling Plates

Semiconductor cooling plates, also known as thermoelectric cooling plates, operate based on the Peltier Effect. When direct current passes through a thermocouple composed of P-type and N-type semiconductor materials, heat is transferred from one end to the other, resulting in one end becoming cold (cold side) and the other end becoming hot (hot side). This cooling method requires neither a compressor nor a refrigerant, enabling miniaturization and precise temperature control.

Calculation Formula and Derivation for Cooling Power

Calculating the actual cooling power of a semiconductor cooling plate is not simply a matter of looking at its input electrical power. Instead, it requires comprehensive consideration of factors such as its operating state and ambient temperature. The core calculation formula is as follows:

Qc = α • I • Tc - 0.5 • I² • R - K • (Th - Tc)

Qc: Actual cooling power at the cold side (W), i.e., the heat absorbed from the cold side, which is the value of primary concern.

α: Seebeck coefficient of the thermocouple pair (V/K), related to the properties of the semiconductor material.

I: Operating current flowing through the cooling plate (A).

Tc: Absolute temperature of the cold side (K).

R: Total resistance of the thermocouple pair (Ω).

K: Total thermal conductivity of the thermocouple pair (W/K).

Th: Absolute temperature of the hot side (K).

The physical meaning of this formula is that the net cooling capacity at the cold side (Qc) equals the cooling generated by the Peltier effect (α • I • Tc), minus half of the Joule heat generated at the cold side (0.5 • I² • R), and further minus the heat conducted back from the hot side to the cold side through thermal conduction (K • (Th - Tc)).

The three terms in the formula represent three distinct thermal effects:

1.Peltier Cooling (α • I • Tc): The heat absorption effect generated when current passes through junctions of different conductors, which is the primary source of cooling.

2.Joule Heat (0.5 • I² • R): Heat generated when current flows through the semiconductor arms, half of which flows to the cold side, offsetting part of the cooling effect.

3.Fourier Heat Conduction (K • (Th - Tc)): Due to the temperature difference between the hot and cold sides, heat naturally conducts from the hot side to the cold side, which also reduces the net cooling effect.

Therefore, the effective cooling power of a semiconductor cooling plate is not equal to its input electrical power (I²R). Typically, the coefficient of performance (COP) is much lower than 1. For example, the cooling efficiency of some cooling plates is generally around 60%, corresponding to a COP of approximately 0.6.

Key Factors Affecting Cooling Power

As evident from the formula, the actual cooling power of a semiconductor cooling plate is not a fixed value. It is influenced by the following key factors:

1. Operating Current (I): There exists an optimal operating current point. If the current is too low, the Peltier effect is weak; if the current is too high, Joule heat increases significantly, potentially reducing cooling efficiency or even damaging the device.

2. Temperature Difference (Th - Tc): The greater the temperature difference between the hot and cold sides, the lower the cooling power. This is because the heat conducted back increases, and the Peltier effect is also affected by temperature. This underscores the critical importance of hot-side heat dissipation: the lower the hot-side temperature, the better the cooling effect and the greater the cooling capacity at the cold side.

3. Semiconductor Material Properties (α, R, K): The material's figure of merit (Z = α² / (R • K)) directly determines the performance limits of the cooling plate. A higher Z value indicates better thermoelectric performance.

Practical Calculation Methods and Online Tools

For specific models of semiconductor cooling plates, HuaJing Temperature Control typically provides performance curves under different hot-side temperatures (Th) and temperature differences (ΔT). These charts are the most intuitive and accurate way to query performance. Based on the known hot-side temperature and the required temperature difference, you can find the corresponding operating current and the cooling power (Qc) at the cold side from the curves.

However, manual calculations and chart referencing can be cumbersome. This is where online calculation tools can be of great assistance.

Principle of Online Tools: Online tools usually embed complex performance curve data in the background. Users only need to input a few key parameters (such as cooling plate model, hot-side temperature, target cold-side temperature, or required heat dissipation capacity), and the tool can quickly estimate the approximate cooling power requirements or recommend suitable models through interpolation calculations.

How to Use: Although specific URLs cannot be provided directly, you can search using keywords such as "semiconductor cooling plate selection tool" or "TEC power calculator" in search engines. Many well-known semiconductor device manufacturers or distributors offer such tools.

Important Note: The results from online calculation tools are estimates and provide an important initial reference for selection. However, before making final design decisions, be sure to conduct detailed verification using the cooling plate's datasheet and perform practical tests whenever possible.

In practical applications, calculating cooling power ultimately aims to ensure proper component selection and system design. Here are two important long-tail keyword directions worth noting:

Semiconductor Cooling Plate Selection Guide: When selecting a cooling plate, not only consider the maximum cooling capacity (Qc max) but also pay attention to the maximum operating voltage and current, maximum temperature difference (ΔT max), as well as the device's dimensions and mechanical structure. Ensure that the selected model provides sufficient cooling capacity under your specific operating conditions (current, temperature difference), not just under ideal conditions.

TEC Cooling System Design: An efficient cooling system involves more than just a cooling plate. Hot-side heat dissipation design is one of the critical factors for success. Based on the total heat that needs to be dissipated at the hot side (Qh = Qc + Pin), select an appropriate cooling method (such as air cooling or water cooling) and heat sink to ensure the hot-side temperature is effectively maintained at a low level. Simultaneously, selecting a sufficiently powerful, stable, and reliable DC power supply to power the cooling plate is also crucial.

Conclusion

Accurately calculating the actual power requirements of a semiconductor cooling plate is a systematic process. It requires an understanding of the underlying thermoelectric principle and the calculation formula  Qc = α • I • Tc - 0.5 • I² • R - K • (Th - Tc), as well as clarity on the combined impact of operating current, temperature difference, and material properties on cooling power. Fully utilizing performance curves provided by manufacturers, such as HuaJing Temperature Control, and online calculation tools for preliminary estimates can significantly improve selection efficiency. However, remember that the ultimate goal of all these calculations and tools is to help you make wiser decisions in the Semiconductor Cooling Plate Selection Guide and TEC Cooling System Design, especially without neglecting the critical aspect of hot-side heat dissipation.

We hope the information provided by HuaJing Temperature Control helps you more clearly determine the cooling power required for your project, thereby designing an efficient and reliable semiconductor cooling system.
